A transformer transfers energy between two or more circuits through electromagnetic induction. Making use of Faraday's Law in combination with high magnetic permeability, transformers efficiently change AC voltages from one voltage level to another within power networks. A wide range of transformer designs are found in current electronic and power applications.
Our company provides a variety of electrical transformers, all of which are open frames, reliable, safe, and long lasting. Equipped with a Class B insulation system, these transfers have been recognized as Class 2 transformers by the Underwriter Laboratories Inc.
Basic Parameters of Transformer
Working Frequency: 50/60Hz;
Dielectric Strength -3500VRMS Hipot;
Technical Specifications of Transformer
| Part No. | VA | Voltage primary | Voltage secondary |
| 20 | 120 | 24 | |
| 40 | 208/240 | 24 | |
| 40 | 120/208/240 | 24 | |
| 50 | 120/208/240 | 24 | |
| 60 | 208/240 | 24 | |
| 60 | 120/208/240 | 24 | |
| 75 | 480 | 24 | |
| 75 | 120/208/240/480 | 24 | |
| 100 | 120/208/240/480 | 24 |
| Part No. | VA | Voltage primary | Voltage secondary |
| 50 | 120/208/240 | 24 | |
| 60 | 240/480 | 24 | |
| 60 | 120/208/240 | 24 | |
| 60 | 120/208/240/480 | 24 | |
| 75 | 120/208/240/480 | 24 | |
| 96 | 240/480 | 24 | |
| 96 | 120/208/240/480 | 24 |
| Part No. | VA | Voltage primary | Voltage |
| 50 | 120/208/240 | 24 | |
| 60 | 240/480 | 24 | |
| 60 | 120/208/240 | 24 | |
| 60 | 120/208/240/480 | 24 | |
| 75 | 120/208/240/480 | 24 | |
| 100 | 240/480 | 24 | |
| 100 | 120/208/240/480 | 24 |
| Part No. | VA | Voltage primary | Voltage secondary |
| 20 | 120 | 24 | |
| 40 | 208/240 | 24 | |
| 40 | 120/208/240 | 24 | |
| 50 | 120/208/240 | 24 | |
| 60 | 208/240 | 24 | |
| 60 | 120/208/240 | 24 | |
| 75 | 120/208/240 | 24 |
| Part No. | VA | Voltage primary | Voltage secondary |
| 50 | 240 | 24 | |
| 50 | 208/240 | 24 | |
| 50 | 120/208/240 | 24 | |
| 50 | 120/208/240/480 | 24 | |
| 50 | 120/208/240 /277/480 |
24 |
