A temperature controller plays an important role in the operation of HVAC or refrigeration systems. We offer several types of refrigeration temperature controllers, all of which share common features that make the controller highly precise and efficient, helping to reduce the energy consumption of the equipment.
Main Features
1) accurate thermometer, clear display and precise temperature control;
2) compressor startup delay function;
3) alarm function for operation errors;
4) switches for refrigeration, heating and alarm.
Specifications
Size: 77.0x34.5x65.5mm
Installing size: 71x29 mm
Operating ambient temperature: -5℃ ~ 60℃
Storage temperature: -30℃ ~ 85℃
Relative humidity: 20%~60% (No condensation)
Technical Parameters
Power supply: 220VAC±10%(12V±10% optional)
Watt consumption: < 5W
Temperature measurement range: -40℃ ~ 99℃
Temperature control range: -40℃ ~ 70℃
Resolution: 1
Measurement accuracy: ±1℃
Relay contact capacity: 10A/250VAC/30VDC
Main Features
1) accurate thermometer, clear display and precise temperature control;
2) compressor startup delay protection function;
3) alarm function when the system temperature exceeds set temperature;
4) adjustable setting for defrost cycle and time.
Specifications
Size: 75x34.5x85 mm
Mounting size: 71x29 mm
Technical Parameters
Power supply: 220VAC+10%-15%, 50/60Hz
Power consumption: ≤3W
Temperature measurement range: -50℃ ~ 99℃
Temperature control range: -40℃ ~ 50℃
Resolution: 1
Accuracy: -40℃~50℃,±1℃,±2℃
Relay capacity of compressor: 7A/220VAC
Relay capacity of Defroster: 7A/220VAC
Sensor error relay time: 1min
Sensor: NTC
Front panel protection level: IP64
Operation temperature: 0℃~60℃
Relative humidity: 20~85%(no condensate)
Storage temperature: -30℃~75℃
Main Features
1) one group of NOC, NCC contactors output;
2) alarm function when the temperature exceeds the preset;
3) upper and lower temperature limits setting to avoid misuse by non-professionals;
4) able to drive single phase comperessor≤1/2HP.
Specifications
Size: 75x34.5x85 mm
Mounting size: 71x29 mm
Technical parameters
Power supply: 220VAC+10%-15%,50/60Hz
Temperature measuring range: -50℃ ~ 99℃
Resolution: 1℃
Refrigeration output contact capacity: 10A/277VAC
Sensor error delay time: 1min
Protection level: IP65
Operation humidity: 20~85%(no condensation)
Power consumption: ≤3W
Temperature controlling range: -40℃~ 50℃
Accuracy: -50℃~70℃, ±1℃, ±2℃
Sensor: NTC, 2M
Operation temperature: 0℃~60℃
Storage temperature: -30℃~75℃
Main Features
1) Multi-control modes for refrigeration, defrosting and fan operation;
2) Separate user and administrator menus for convenience;
3) Differential control mode and high resolution temperature display;
4) Multiple protective and warning alerts;
5) COPY KEY function (optional).
Specifications
Size: 75x34.5x85 mm
Mounting size: 71x29 mm
Technical parameters
Temperature measuring and controlling range: -50℃ ~ 50℃
Power supply: 220VAC 50Hz
Power consumption: < 5W
Ambient temperature: 0℃ ~ 60℃
Relative humidity: 20~85% (no condensation)
Measurement accuracy: ±1℃
Relay capacity of compressor: 8A/220VAC
Relay capacity of fan and defrost: 8A/220VAC
Digital display: three-digit LED + minus digit + status indicator light
